Technical Specifications & Measurements.

Basic performance specifications for the R80 IBX (inboard) & OBX (outboard) crossover variants are itemised below.

R80 Loudspeaker


Sensitivity:	92dB (2.83v @1m)
Nominal Impedance:	6 Ohms
Minimum Impedance:	4.5 Ohms
Loading:	Reflex port to rear of cabinet.
Frequency Response:	25Hz–20kHz
Power Handling:	100 Watts
Cabinet Dimensions:	W 310mm × D 423mm × H 1090mm
Plinth:	490mm wide at the front, tapering to 430mm wide at the rear, × 423mm D × 60mm H. Black satin finish.
Gross Weight:	48.1 Kgs per cabinet (IB-X); 45.5 Kgs per cabinet (OB-X); 8 Kgs per Crossover (OB-X); 4.5 Kgs per R80 Plinth.
Crossover Dimensions (in ‘suitcase’ orientation):	W 120mm × D 450mm × H 270mm

Sensitivity:

92dB (2.83v @1m)

Nominal Impedance:

6 Ohms

Minimum Impedance:

4.5 Ohms

Loading:

Reflex port to rear of cabinet.

Frequency Response:

25Hz–20kHz

Power Handling:

100 Watts

Cabinet Dimensions:

W 310mm × D 423mm × H 1090mm

Plinth:

490mm wide at the front, tapering to 430mm wide at the rear, × 423mm D × 60mm H. Black satin finish.

Gross Weight:

48.1 Kgs per cabinet (IB-X);
45.5 Kgs per cabinet (OB-X);
8 Kgs per Crossover (OB-X);
4.5 Kgs per R80 Plinth.

Crossover Dimensions
(in ‘suitcase’ orientation):

W 120mm × D 450mm × H 270mm

Scanspeak Ellipticor 34mm Dome tweeter 4ohm. Elliptical Voice coil. Neo AirCirc 120mm.

Scanspeak Ellipticor 21cm Midwoofer 8ohm. Paper cone. Elliptical Voice Coil. Neo AirCirc.

Accessory Box with 8 pcs of spikes, floor protectors and 2 spanners enabling easy height adjustment of the loudspeaker in-situ: 1 spanner for rotating the spike and 1 for locking it.

Cabinets made in premium furniture grade, book-matched veneers. Outboard crossovers (where supplied) finished in matching book matched veneers. Glossy Ebony or Satin Ebony / Glossy Santos or Satin Santos / Pippy Oak. Other finishes & RAL by special order.
